SiLine®-Series
Vending in perfection
The operating concept - simply ingenious
The uniform operating concept via touch screen extends over the entire SiLine® machine line. The intuitive and comfortable menu guides guests and personnel quickly to their desired destination. Other additional functions such as the storage of important consumer information such as ingredients, allergens or additional information or the display of advertising banners inspire and increase your sales success. The shopping cart function makes it possible to order up to five products in one purchase process. With the deal function, guests can choose from several products as a menu offer. This increases local sales with attractive combinations from the product range.
SiLine® series variants
General information
- Ease to operate using 27“ touchscreen behind full-surface glass front
- Product descriptions possible for each selection
- Presentation of consumer information such as ingredients, allergens or additional information
- Large, open dispense outlet with optional RGB-user prompting
- Dry sugar and stirrers
- Innovative instant containers with SiTwist'n-Lock system
- Configurable advertising space or Slideshow area for advertising videos and images
| Dimensions: | 1,830 x 700 x 755 mm (height x width x depth)* |
| Weight: | approx. 210 kg |
| Cup capacity: | can dispense up to 180 cups per hour (varies depending on product and setting) |
| Electrical data: | 220 - 230 V / 50/60 Hz / min. 10 A |
| Power: | 2,3 kW |
| Water connection: | John Guest |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from stainless steel
- Design RA = Lower design panel RAL painted
Housing colours
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration stripes
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
General information
- Fits perfectly into a SiVend-Line
- The "Trend" variant features an additional advertising Panel
- Ease to operate using 27“ touchscreen behind full-surface glass front
- Product descriptions possible for each selection
- Presentation of consumer information such as ingredients, allergens or additional information
- Large, open dispense outlet with optional RGB-user prompting
- Dry sugar and stirrers
- Innovative instant containers with SiTwist'n-Lock System
*Deviations in the housing dimensions are possible due to add-on parts and accessories. |
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
General information
- Ease to operate using 20 capacitive keys with large product decals
- Product information and programming via 7" touch display
- Large, open dispense outlet with optional RGB-user prompting
- Dry sugar and stirrers
- Innovative instant containers with SiTwist'n-Lock system
| Dimensions: | 1,830 x 700 x 755 mm (height x width x depth)* |
| Weight: | approx. 210 kg |
| Cup capacity: | can dispense up to 180 cups per hour (varies depending on product and setting) |
| Electrical data: | 220 - 230 V / 50/60 Hz / min. 10 A |
| Power: | 2,3 kW |
| Water connection: | John Guest |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from stainless steel
- Design RA = Lower design panel RAL painted
Housing colours
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration stripes
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
General facts
- Fits perfectly into a SiVend-Line
- The "Trend" variant features an additional advertising panel
- The operator module is on the right hand side and runs vertically to the base of the machine
- Ease to operate using 20 capacitive keys with large product decals
- Product information and programming via 7" touch display
- Large, open dispense outlet with optional RGB-user prompting
- Dry sugar and stirrers
- Innovative instant containers with SiTwist'n-Lock system
*Deviations in the housing dimensions are possible due to add-on parts and accessories. |
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
Introduction
- Vending of glass bottles, PET bottles and cans from 0.2 l to 0.6 l
- For products ranging from 200 to 910 grams and with a diameter ranging from 53 mm to 72 mm
- Max. bottle height: 270 mm
- Up to 8 shelves
- 7 to 8 selections per shelf
- Modular design - especially easy to service and recycle
| Dimensions: | 1,830 x 990 x 895 mm (height x width x depth)* |
| Weight: | approx. 330 kg (in standard configuration with 5 shelves) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 - 750 W (varies depending on the type of chiller unit) |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A or B.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
Design package B includes:
- LED-Decoration strips above and below the glass panel
- Upper door decoration panel in stainless steel
- Kickplate in stainless steel
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
- For cans and bottles up to Ø 72 mm
- Max. Height 240 mm
- 35 types - approx. 315 drinks
- Typical layout for PET-bottles up to 0.6 l
- For cans and bottles up to Ø 72 mm
- Max. height of bottles up to 240 mm; cans up to 145 mm
- 42 types - approx. 378 drinks
- Typical layout for PET bottles up to 0.6 l; standard cans 0.33 l
- For cans and bottles up to Ø 62 mm
- Max. Height 146 mm
- 56 types - approx. 616 drinks
- Typical layout for slim cans 0.25 l and sleek cans 0.33 l
- For cans and bottles up to Ø 72 mm
- Max. Height 116 mm
- 56 types - approx. 504 drinks
- Typical layout for standard 0.33 l cans
Introduction
- Vending of glass bottles, PET bottles and cans from 0.2 l to 0.6 l
- For products ranging from 200 to 910 grams and with a diameter ranging from 53 mm to 72 mm
- Max. bottle height: 270 mm
- Up to 8 shelves
- 9 to 10 selections per shelf
- Modular design - especially easy to service and recycle
| Dimensions: | 1,830 x 1,140 x 895 mm (height x width x depth)* |
| Weight: | Approx. 360 kg (in standard configuration with 5 shelves) |
| Electrical connection values: | 220 - 230 V~ / 50 Hz / min. 10 A |
| Power consumption: | 400 - 750 W (varies depending on the type of chiller unit) |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A or B.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
Design package B includes:
- LED-Decoration strips above and below the glass panel
- Upper door decoration panel in stainless steel
- Kickplate in stainless steel
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
- For cans and bottles up to Ø 72 mm
- 45 types - approx. 405 drinks
- Typical layout for PET-bottles up to 0.6 l
- For cans and bottles up to Ø 72 mm
- 54 types - approx. 486 drinks
- Typical layout for PET bottles up to 0.6 l Standard cans 0.33 l
- For cans and bottles up to Ø 62 mm
- 70 types - approx. 770 drinks
- Typical layout for slim cans 0.25 l and sleek cans 0.33 l
- For cans and bottles up to Ø 72 mm
- 72 types - approx. 648 drinks
- Typical layout for standard 0.33 l cans
Introduction
- Anti-vandalism panel made from 12mm thick polycarbonate
- Reinforced, wavy shaped locking lever protection; this corrugated profile prevents forced opening or burglary
- Insulating laminated safety glass panel
- Door split cover
| Dimensions with door split cover: | 1,839 x 999 x 904 mm (height x width x depth)* |
| Dimensions with anti-theft protection frame and side lock: | 1,850 x 1,055 x 904 mm (height x width x depth)* |
| Weight: | approx. 370 kg (in standard version) |
| Weight with anti-theft protection frame and side lock: | approx. 380 kg |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 - 750 W (varies depending on the type of chiller unit) |
| Anti-vandalism panel: | Standard 12 mm PC Optional 8 mm theft prot. anti-vandalism panel |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
- 8 mm thick vandal-proof panel
- Anti-theft prot. frame with side lock and CES mortise lock (optional KESO)
- Heater ('Frost monitoring function'): The internal temperature is held above 0 °C)
- Laminated safety glass panel with UV filter
| Dimensions with door split cover: | 1,839 x 1,149 x 904 mm (height x width x depth)* |
| Dimensions with anti-theft protection frame and side lock: | 1,850 x 1,205 x 904 mm (height x width x depth)* |
| Weight: | approx. 400 kg (in standard version) |
| Weight with anti-theft protection frame and side lock: | approx. 410 kg |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 750 W (varies depending on the type of chiller unit) |
| Anti-vandalism panel: | Standard 12 mm PC Optional 8 mm theft prot. anti-vandalism panel |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
- 8 mm thick vandal-proof panel
- Anti-theft prot. frame with side lock and CES mortise lock (optional KESO)
- Heater ('Frost monitoring function'): The internal temperature is held above 0 °C)
- Laminated safety glass panel with UV filter
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
Introduction
- Protection class: IP24
- Winter resistant up to -20°C
- Rain roof and weatherproof protection
- Impact protection (Standard 12 mm PC)
- Laminated safety glass with UV-light filter (ESG safety glass)
- Reinforced wavy locking lever protection (5 mm stainless steel), the wavy profile prevents prising or lifting
- Coin insert slide and coin return drum
- High security frame with side lock and CES mortice lock (KESO as an option)
- Residual current circuit breaker
- Chiller unit with heater (”Frost monitoring function“, which keeps the internal temperature above 0 °C)
- Rear wall (Branding opportunity)
| Dimensions: | 1,866 x 1,210 x 1,000 mm (height x width x depth)* |
| Weight: | approx. 480 kg |
| Electrical connection values: | 220 – 230 V / 50 Hz / min. 10 A |
| Power consumption: | 750 W |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A or B.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
Design package B includes:
- LED-Decoration strips above and below the glass panel
- Upper door decoration panel in stainless steel
- Kickplate in stainless steel
- Anti-vandalism panel
- Rain shield and weatherproof protection
- Coin insert slide and coin return drum
- Reinforced locking lever protection
- Security frame with side lock
- Laminated safety glass panel with UV filter
- Residual current circuit breaker
- High performance chiller unit with heater with "frost monitoring function", so that the internal temperature is held above 0°C
- Rear panel offers advertising opportunity
- KESO
Optional
- Impact protection made of 8 mm thick laminated safety glass instead of 12mm PC
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
Introduction
- They can be used to sell confectionery, snacks, fresh food, beverages and nonfood items from spiral, pusher and conveyor belt drawers
- High capacity: up to 7 shelves
- Fits in a Vending line
- Shelves and spirals made from powder-coated metal
- SiLine® Combi: Pushers suitable for products with a diameter up to 72 mm
- Uniform installation area for the payment systems
- Modular design – especially easy to service and recycle
| Dimensions: | 1,830* x 780 x 895 mm (height x width x depth)** |
| Weight: | approx. 300 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 6 |
| Pusher per shelf: | 6 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
| Dimensions: | 1,830* x 780 x 895 mm (height x width x depth)** |
| Weight: | approx. 300 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 6 |
| Pusher per shelf: | 6 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
Introduction
- They can be used to sell confectionery, snacks, fresh food, beverages and nonfood items from spiral, pusher and conveyor belt drawers
- High capacity: up to 7 shelves
- Fits in a Vending line
- Shelves and spirals made from powder-coated metal
- SiLine® Combi: Pushers suitable for products with a diameter up to 78 mm
- Uniform installation area for the payment systems
- Modular design – especially easy to service and recycle
| Dimensions: | 1,830* x 990 x 895 mm (height x width x depth)** |
| Weight: | approx. 340 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 9 |
| Pusher per shelf: | 8 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
| Dimensions: | 1,830* x 990 x 895 mm (height x width x depth)** |
| Weight: | approx. 340 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 9 |
| Pusher per shelf: | 8 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
Introduction
- "Fresh Food" storage ≤ + 4 °C throughout the machine
- The "Food safety software" monitors the temperature in the LM-zone and ensures that only properly chilled products are dispensed.
- Frost monitor
- 6 or 7 product shelves by default
- Capacity: Up to 9 selections per shelf, up to 7 shelves
| Dimensions: | 1,830* x 780 x 895 mm (height x width x depth)** |
| Weight: | approx. 300 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 6 |
| Pusher per shelf: | 6 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
| Dimensions: | 1,830* x 990 x 895 mm (height x width x depth)** |
| Weight: | approx. 340 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 9 |
| Pusher per shelf: | 8 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
Introduction
- 2T-variant: split temperature zones separated by directed air flow, Fresh food / snack
- Approx. + 10 - 15 °C on the upper shelves
- Food-safety storage at ≤ + 4 °C on the lower shelves (LM zone) - The temperature separation position can be adjusted within a pre-defined range
- The Food safety software monitors the temperature in the LM-zone and ensures that only properly chilled products are dispensed
- Frost monitor
| Dimensions: | 1,830* x 780 x 895 mm (height x width x depth)** |
| Weight: | approx. 300 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 6 |
| Pusher per shelf: | 6 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
| Dimensions: | 1,830* x 990 x 895 mm (height x width x depth)** |
| Weight: | approx. 340 kg (without products, depending on the layout) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Power consumption: | 400 W (varies depending on the type of chiller unit) |
| Spirals per shelf: | 9 |
| Pusher per shelf: | 8 |
* 1,844 mm for Design VA with Design package B
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Lift
- Light barrier
Introduction
- Public variant
- Effective protection against theft, vandalism and tampering
- 12 mm thick anti-vandalism panel made from polycarbonate
- Reinforced, wavy shaped locking lever protection; the corrugated profile prevents forced opening or burglary
- Coin insert slide and coin return drum
- Insulating laminated glass panel
- Door split cover
| Dimensions: | 1,839 x 789 x 907 mm (height x width x depth with door split cover)* 1,850 x 843 x 907 mm (height x width x depth with anti-theft protection frame and side lock)* |
| Weight: | Approx. 330 kg (in standard version) Approx. 340 kg (with anti-theft protection frame and side lock) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Output: | 400 W (varies depending on the type of chiller unit) |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Anti-vandalism panel made from 8mm thick glass
- Security frame with side lock and CES mortise lock (optional KESO)
- Heater with 'frost monitoring function': Ensures the internal temperature is held above 0 °C
- Laminated safety glass panel with UV filter
- Metal keypad in combination with an anti-vandalism panel in front of the touch display
| Dimensions: | 1,839 x 999 x 907 mm (height x width x depth with door split cover)* 1,850 x 1,053 x 907 mm (height x width x depth with anti-theft protection frame and side lock)* |
| Weight: | Approx. 380 kg (in standard version) Approx. 390 kg (with anti-theft protection frame and side lock) |
| Electrical connection values: | 220 - 230 V / 50 Hz / min. 10 A |
| Output: | 400 W (varies depending on the type of chiller unit) |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
- Anti-vandalism panel made from 8mm thick glass
- Security frame with side lock and CES mortise lock (optional KESO)
- Heater with 'frost monitoring function': Ensures the internal temperature is held above 0 °C
- Laminated safety glass panel with UV filter
- Metal keypad in combination with an anti-vandalism panel in front of the touch display
Introduction
- Protection class: IP24
- Winter resistant up to -20°C
- Rain roof and weatherproof protection
- Impact protection (Standard 12 mm PC)
- Laminated safety glass with UV-light filter (ESG safety glass)
- Reinforced wavy locking lever protection (5 mm stainless steel), the wavy profile prevents prising or lifting
- Coin insert slide and toothed coin return drum
- High security frame with side lock and CES mortice lock (KESO mortice lock as an option)
- KESO door lock
- Residual current circuit breaker
- Chiller unit with heater (”Frost monitoring function“, which keeps the internal temperature above 0 °C)
- Rear wall (Branding opportunity)
| Dimensions: | 1,866 x 1,056 x 1,000 mm (height x width x depth)* |
| Weight: | approx. 440 kg |
| Electrical connection values: | 220 – 230 V / 50 Hz / mind. 10 A |
| Power consumption: | 750 W |
*Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A or B.
Design RA can be complemented with Design package A.
Design package A includes:
- LED-Decoration strips above and below the glass panel
Design package B includes:
- LED-Decoration strips above and below the glass panel
- Upper door decoration panel in stainless steel
- Kickplate in stainless steel
Optional
- Lift
- Impact protection made of 8 mm thick laminated safety glass instead of 12mm PC
- KESO mortice lock
You can find instructions and publicly available documents under Downloads.
Further information and downloads are available to registered customers in the Sielaff Customer Center. Don’t have access yet?
You can easily register for the customer login.
Introduction
- Reverse vending of disposable and reusable PET bottles, cans and cups with EAN code
- Barcode recognition (up to 20,000 codes)
- Acceptance speed: Up to 30 empties per minute
- Capacity: Up to 400 bottles (0.5 l PET) or up to 560 cans
- Fits perfectly in a Vending line with other SiLine and vending machines
- Optimal range of application: closed environment such as company canteens
- Modular design - makes it extremely easy to service and recycle
| Dimensions: | 1.830* x 780 x 716 mm (height x width x depth)** |
| Weight: | Approx. 145 kg |
| Container size: | Max. diameter 140 mm; Max. lenght 380 mm |
| Acceptance speed: | Up to 30 units per minute |
| Capacity: | Approx. 400 bottles (0,5 l PET) or approx. 560 cans |
| Electrical connection values: | 220 – 230 V / 50/60 Hz /mind. 10 A |
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
Features:
- Rotating drum
- Coin hopper holds up to 2,000 coins
- Barcode scanner recognition range approx. 170 mm
- Packaging recognition
- Sluice gate function in the acceptance area
- LED-strip Status indicator
Optionen:
- Up to 2 coin hoppers possible
- Sorting into two Sections
- SiDrop (with SiLine SiOne M only)
- Roller container (with SiLine SiOne S only)
- Receipt printer
- Ingress protection, Thread catcher
- Product recognition (cup acceptance is possible either with or without barcodes)
Introduction
- Reverse vending of disposable and reusable PET bottles, cans and cups with EAN code
- With the SiDrop glass bottles can be accepted as an option
- Barcode recognition (up to 20,000 codes)
- Acceptance speed: Up to 30 empties per minute
- Capacity: Up to 700 bottles (0.5 l PET) or up to 850 cans
- Optional:
SiDrop, approx. 350 bottles (0.5 l glass. For mixed acceptance including also smaller bottles, a higher capacity is achievable) - Fits perfectly in a Vending line with other SiLine and vending machines
- Optimal range of application: closed environment such as company canteens
- Modular design - makes it extremely easy to service and recycle
| Dimensions: | 1.830* x 990 x 895 mm (height x width x depth)** |
| Weight: | Approx. 200 kg |
| Container size: | Max. diameter 140 mm; Max. lenght 380 mm |
| Acceptance speed: | Up to 30 units per minute |
| Capacity: | Approx. 700 bottles (0,5 l PET) or approx. 850 cans |
| Electrical connection values: | 220 – 230 V / 50/60 Hz /mind. 10 A |
**Deviations in the housing dimensions are possible due to add-on parts and accessories.
Design panel
- Design VA = Lower design panel made from Stainless steel
- Design RA = Lower design panel RAL painted
Cabinet colours
- Pure white (RAL 9010)
- White aluminum (RAL 9006)
- Jet black (RAL 9005)
Optional:
The standard design VA can be added with the design package A.
Design RA can be complemented with Design package A.
Design package A includes:
- LED decoration panel
Features:
- Rotating drum
- Coin hopper holds up to 2,000 coins
- Barcode scanner recognition range approx. 170 mm
- Packaging recognition
- Sluice gate function in the acceptance area
- LED-strip Status indicator
Optionen:
- Up to 2 coin hoppers possible
- Sorting into two Sections
- SiDrop (with SiLine SiOne M only)
- Roller container (with SiLine SiOne S only)
- Receipt printer
- Ingress protection, Thread catcher
- Product recognition (cup acceptance is possible either with or without barcodes)
An overview of the benefits
Touch display
Touch display
- Uniform operating concept applies to the entire SiLine® vending machine line
- Intuitive and convenient menu
- Shopping cart feature: Allows to order up to five products
- Deal feature: Several products can be selected as a menu offer.
- Additional features: Storing important consumer information such as ingredients, allergens or additional information or advertising banners
Particularly quiet
Particularly quiet
- The SiLine® series machines are particularly quiet during product dispense
- Recommended for sensitive areas such as lobby and reception
Line design
Line design
- High quality and state-of-the art, appealing design
- There are various designs and features to choose from
- The continuous LED light strip is a real eye-catcher in any environment
- The uniform line design guarantees a consistently positive impression
